Model XD381XG
| Size | DN | A (mm) | B (mm) | C (mm) | F Pipe OD (mm) | G Groove diameter (mm) | L Length (mm) | L1 (mm) | L2 (mm) | H1 (mm) | H (mm) | W (mm) | ΦE (mm) | ΦF (mm) | N-ΦM | ISO 5211 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2" | DN50 | 89 | 65 | 81 | 60.3 | 57.15 | 122.5 | 7.93 | 15.88 | 127 | 202.2 | 125 | 70 | 90 | 4-Φ10 | F07 |
| 2-1/2" | DN65 | 102 | 71 | 97 | 73.0 | 69.09 | 122.5 | 7.93 | 15.88 | 127 | 202.2 | 125 | 70 | 90 | 4-Φ10 | F07 |
| 3" | DN80 | 109 | 81 | 97 | 88.9 | 84.94 | 122.5 | 7.93 | 15.88 | 127 | 202.2 | 125 | 70 | 90 | 4-Φ10 | F07 |
| 4" | DN100 | 128 | 95 | 116 | 114.3 | 110.08 | 122.5 | 9.53 | 15.88 | 127 | 202.2 | 125 | 70 | 90 | 4-Φ10 | F07 |
| 5" | DN125 | 141 | 111 | 148 | 141.3 | 137.03 | 122.5 | 9.53 | 15.88 | 127 | 202.2 | 125 | 70 | 90 | 4-Φ10 | F07 |
| 6" | DN150 | 153 | 133 | 148 | 168.3 | 163.96 | 122.5 | 9.53 | 15.88 | 139.5 | 215 | 225 | 70 | 90 | 4-Φ10 | F07 |
| 8" | DN200 | 184 | 164 | 133 | 219.1 | 214.40 | 122.5 | 11.10 | 19.05 | 198.5 | 274 | 225 | 102 | 125 | 4-Φ12 | F10 |
| 10" | DN250 | 216 | 196 | 159 | 273.1 | 268.28 | 122.5 | 12.70 | 19.05 | 198.5 | 274 | 225 | 102 | 125 | 4-Φ12 | F10 |
| 12" | DN300 | 254 | 226 | 165 | 323.9 | 318.29 | 132.0 | 12.70 | 19.05 | 198.5 | 293.5 | 225 | 102 | 125 | 4-Φ12 | F10 |
98 projects and 61 owners approved this product or its family through the project consultants.
and 86 more projects.
Original approval letters are provided on request with your submittal.
MECH XD381XG grooved butterfly valve with normally closed tamper switch, groove to AWWA C606, 2″–12″, 363 PSI, UL listed. Exclusive MECH agent in Saudi Arabia.
