Model XD371XG
| Size | DN | A (mm) | B (mm) | C (mm) | L (mm) | H1 (mm) | H (mm) | W (mm) | ISO 5211 | ΦE (mm) | ΦF (mm) | N-ΦM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2" | DN50 | 140.5 | 65 | 43 | 122.5 | 127 | 202.2 | 125 | F07 | 70 | 90 | 4-Φ10 |
| 2-1/2" | DN65 | 153 | 71 | 46 | 122.5 | 127 | 202.2 | 125 | F07 | 70 | 90 | 4-Φ10 |
| 3" | DN80 | 157.5 | 81 | 46 | 122.5 | 127 | 202.2 | 125 | F07 | 70 | 90 | 4-Φ10 |
| 4" | DN100 | 176 | 95 | 52 | 122.5 | 127 | 202.2 | 125 | F07 | 70 | 90 | 4-Φ10 |
| 5" | DN125 | 191 | 111 | 56 | 122.5 | 127 | 202.2 | 125 | F07 | 70 | 90 | 4-Φ10 |
| 6" | DN150 | 202.5 | 133 | 56 | 122.5 | 139.5 | 215 | 225 | F07 | 70 | 90 | 4-Φ10 |
| 8" | DN200 | 243.5 | 164 | 60 | 122.5 | 198.5 | 274 | 225 | F10 | 102 | 125 | 4-Φ12 |
| 10" | DN250 | 273 | 196 | 68 | 122.5 | 198.5 | 274 | 225 | F10 | 102 | 125 | 4-Φ12 |
| 12" | DN300 | 311 | 226 | 78 | 132 | 198.5 | 293.5 | 225 | F10 | 102 | 125 | 4-Φ12 |
98 projects and 61 owners approved this product or its family through the project consultants.
and 86 more projects.
Original approval letters are provided on request with your submittal.
MECH XD371XG wafer butterfly valve with normally closed tamper switch, for ASME B16.1 CL125 / B16.42 CL150 flanges, 2″–12″, 300 PSI, UL listed. Exclusive MECH agent in Saudi Arabia.
