TYCO Series TY-B Sprinklers — Standard Response, K5.6 (TFP152)

2 models View models

Brand
TYCO
Series
TY-B
Models
TY315, TY325
Orientation
Upright, Pendent / Recessed Pendent
K-factor
5.6 gpm/psi½
Thread connection
1/2" NPT
Response
Standard Response
Coverage
Standard Coverage
Temperature ratings
57 / 68 / 79 / 93 / 141 / 182 °C
Max. working pressure
175 psi (12.1 bar); 250 psi (17.2 bar) under UL
Approvals
UL · C-UL · FM · LPCB · VdS (per Table A)
Datasheet
TFP152
Request a quote for this product
Or buy from the online store

Models in this series 2

Each model has its own number and is ordered by it. Tap a model to jump to it, or add it straight to your request list.

ModelOrientationK-factorThreadResponseOrder
TY315Upright5.61/2" NPTStandard Response
TY325Pendent / Recessed Pendent5.61/2" NPTStandard Response

TYCO Series TY-B (datasheet TFP152) are upright and pendent / recessed pendent sprinklers with a K 5.6 discharge coefficient, standard response and standard coverage, operated by a glass bulb 5 mm. They are designed for light, ordinary and extra-hazard occupancies such as banks, hotels, shopping malls, factories, refineries and chemical plants. The series has 2 models; each has a Sprinkler Identification Number (SIN) that fixes its orientation, K-factor and thread, and the sprinkler is ordered by that number. The models table at the top of this page lists them all; for where the sprinkler sits in the whole system, see the complete guide to sprinkler systems in Saudi Arabia.

In short

  • Models: TY315, TY325.
  • Orientations: Upright and Pendent / Recessed Pendent.
  • K-factor: K 5.6; thread: 1/2″ NPT.
  • Glass bulb 5 mm, standard response.
  • Temperature ratings: 57 / 68 / 79 / 93 / 141 / 182 °C.
  • Maximum working pressure: 175 psi (12.1 bar); 250 psi (17.2 bar) under UL.
  • Series approvals: UL, C-UL, FM, LPCB, VdS (per Table A). The approval of each model, finish and rating is in the approvals table of datasheet TFP152.

How this sprinkler works

The glass bulb contains a fluid that expands when exposed to heat. When the rated temperature is reached, the fluid expands enough to shatter the bulb, the sprinkler opens and the deflector spreads the water over the fire area.

Upright: Installed above the pipe with the deflector facing up.

Pendent / Recessed Pendent: Installed hanging below the pipe; it can also be recessed into a finished ceiling with its specified recessed escutcheon.

Standard response is typically used for storage and industrial areas, per the project design.

How to choose the model

  • Orientation: from the pipe and ceiling layout — upright above the pipe in open ceilings, pendent or recessed below a finished ceiling, sidewall along a wall.
  • K-factor: K 5.6 for every model in the series.
  • Thread: usually follows the K-factor, and must match the fitting on the system.
  • Temperature rating and finish: stated with the order for each model, from the highest expected ceiling temperature and the environment.

Application notes

  • Datasheet TFP152 covers TY315 and TY325 at K 5.6 only; guards and shields are described in TFP780.
  • Corrosion-resistant finishes are available per the datasheet for corrosive atmospheres; the datasheet notes that corrosion tests do not represent every possible atmosphere, so suitability for the actual environment should be checked.

Technical data

Technical data for Series TY-B per TYCO datasheet TFP152
ItemValue
Models (SIN)TY315, TY325
OrientationsUpright and Pendent / Recessed Pendent
Discharge coefficientK 5.6 (80.6 L/min/bar½)
Thread1/2″ NPT
ElementGlass bulb 5 mm
ResponseStandard Response
CoverageStandard Coverage
Temperature ratings57 / 68 / 79 / 93 / 141 / 182 °C
Maximum working pressure175 psi (12.1 bar); 250 psi (17.2 bar) under UL
Installation torque7 – 14 lb-ft (9.5 – 19.0 N·m)
WrenchW-Type 6 (W-Type 7 for recessed)
EscutcheonRecessed pendent: Style 15 or Style 20 only
ApprovalsUL, C-UL, FM, LPCB, VdS (per Table A)
DatasheetTYCO TFP152

The critical point: torque

Torque this sprinkler 7 – 14 lb-ft (9.5 – 19.0 N·m) with the W-Type 6 wrench, or the W-Type 7 for recessed installations. Higher torque can distort the inlet and cause leakage.

Installation steps

  1. Inspect before installing: never install a sprinkler whose bulb is cracked or has lost liquid.
  2. Install each sprinkler in the correct orientation for its model, as shown in the datasheet — never reversed.
  3. Apply pipe-thread sealant to the threads, then hand-tighten the sprinkler.
  4. Finish with the specified wrench (W-Type 6 (W-Type 7 for recessed)) within the torque for the model’s thread: 7 – 14 lb-ft (9.5 – 19.0 N·m). Higher torque can distort the inlet and cause leakage.
  5. With an escutcheon, use only the specified one (Recessed pendent: Style 15 or Style 20 only) and never compensate for adjustment by changing the torque.

Common mistakes

  • Compensating for too little recessed escutcheon adjustment by under- or over-tightening instead of readjusting the fitting.
  • Installing a sprinkler that was dropped, struck or slipped by the wrench. The datasheet requires any such sprinkler to be replaced.
  • Painting or coating sprinklers on site. Sprinklers must not be altered after leaving the factory; altered sprinklers are replaced.
  • Hanging objects from sprinklers, or cleaning them with anything other than a gentle feather duster.

Maintenance

Sprinklers that leak or show visible corrosion must be replaced, as must sprinklers exposed to corrosive products of combustion that cannot be fully cleaned. The owner is responsible for inspection, testing and maintenance to NFPA 25 and the authority having jurisdiction, preferably by a qualified inspection service. Before closing a main control valve for maintenance, obtain permission from the proper authorities and notify everyone affected.

Files and ordering

TYCO datasheet TFP152 and the available approval certificates are in the files section of this page. When ordering, state for each line the model (SIN), temperature rating and finish, escutcheon. The datasheet lists the part numbers (P/N) for each combination.

How to order

Use the “Build your order” section on this page: add every model and quantity, then send the whole order by email or WhatsApp. It reaches us as a tidy PDF request sheet and we contact you with the quotation.

FAQ

What do model numbers such as TY315 mean?

They are TYCO Sprinkler Identification Numbers (SIN). Each identifies an exact model — orientation, K-factor and thread. The sprinkler is ordered by this number together with temperature rating and finish.

How do I choose the temperature rating?

From the highest expected ceiling temperature and the rating classes in the project’s governing standard, within the ratings available for the model in the datasheet.

Do all models in the series carry the same approvals?

Not always. The approvals table in datasheet TFP152 gives each model’s approvals by rating and finish, so check it when the project requires a specific approval.

References

  • TYCO TFP152 — Series datasheet (attached)
  • NFPA 13 — Standard for the Installation of Sprinkler Systems
  • NFPA 25 — Inspection, Testing and Maintenance of Water-Based Fire Protection Systems
  • TYCO TFP700 — Installer warning for handling and installing sprinklers

This page is general information to help with selection and ordering, taken from the attached TYCO datasheet. Final design is set by the project’s approved designer; the project specification, the consultant’s drawings and the latest datasheet revision govern.
