MECH BRASS TRIANGLE LOCK GATE VALVE MODEL : JZ15W-104A

Model JZ15W-104A

Connection ends
Threaded ISO 228
Working pressure
PN16
Sizes
1/2" – 2" (DN15 – DN50)
Request a quote for this product
Or buy from the online store
Certificates & approvals

Ask us for this product's certificates.

SIZES & DIMENSIONS

Sizes & dimensions

SizeDNA (mm)B (mm)C (mm)F (mm)SW (mm)
1/2"DN1561431312.525
3/4"DN2065471713.531.5
1"DN257349.521.51438
1-1/4"DN327554261547
1-1/2"DN4078563115.553
2"DN509864401766

The MECH brass triangle lock gate valve, model JZ15W-104A, sizes 1/2″ – 2″ (DN15 – DN50), working pressure PN16. A handwheel isolating valve for small water lines. This guide explains what it does and how it works, related models, technical data, the critical point in selection and installation, and common mistakes.

At a glance

  • A brass gate valve lifts a gate inside the body with its handwheel; fully open the waterway is almost clear and pressure loss is low.
  • Sizes 1/2″ – 2″ (DN15 – DN50).
  • Working pressure PN16.
  • Connection: Threaded ISO 228.

Brass gate valve: what it does and how it works

A brass gate valve lifts a gate inside the body with its handwheel; fully open the waterway is almost clear and pressure loss is low.

It isolates small water and service lines. The locking models (triangle or magnetic) only operate with a special key, preventing tampering in public areas.

Related models

brass gate valve family
ModelProductSizesPressureApprovals
Z15W-101ABRASS GATE VALVE1/2″ – 2″ (DN15 – DN50)PN16—
JZ15W-104A — this productBRASS TRIANGLE LOCK GATE VALVE1/2″ – 2″ (DN15 – DN50)PN16—
CZ15W-103ABRASS MAGNETIC ENCRYPTION GATE VALVE1/2″ – 2″ (DN15 – DN50)PN16—

Technical data

Specification of model JZ15W-104A
ItemSpecification
Connection endsThreaded ISO 228
Working pressurePN16
Sizes1/2″ – 2″ (DN15 – DN50)

Dimensions for every size are in the size table at the top of the page.

Parallel or taper thread

An ISO 228 parallel thread does not seal by interference, so sealing relies on a gasket, washer or suitable compound; NPT and ISO 7-1 are taper threads that seal on the thread with sealant. Choose the valve with the same thread as the pipe and fittings.

Caution

A gate valve is for full open or shut, not for throttling.

Installation steps

  1. Check the thread type (ISO 228 parallel or NPT / ISO 7-1 taper) matches the pipe, and use the sealant or gasket suited to that thread.
  2. Hold the valve with the wrench on the end being tightened, not on the body or handle.
  3. Do not over-tighten, so the brass body is not distorted.
  4. Operate the valve after installation to check movement and sealing.

Common mistakes

  • Mixing parallel and taper threads.
  • Tightening by the valve body or handle.
  • Over-tightening the brass body.

Files and ordering

On this page: Product page (catalogue), MECH Brass Valves Catalogue. Add the product to your request list with size and quantity and we send a quotation, or build a submittal PDF for the consultant. Fu-Mech is the exclusive MECH agent in Saudi Arabia.

Frequently asked questions

What is the locking valve for?

It only opens and shuts with a special key, preventing tampering in public buildings and shared meters.

Can it throttle flow?

No, the seat wears; use it fully open or shut.

What is the working pressure of model JZ15W-104A?

PN16 per the product data. The pressure for each size or listed model is in the size table and datasheet.

What end connection does it have?

Threaded ISO 228. Choose the connection that matches the adjacent pipe and fittings.

References

  • ISO 228 — Pipe threads where pressure-tight joints are not made on the threads
  • MECH catalogue — MECH brass valves

This guide is general information to help with selection. Figures come from the product data on this page and the MECH catalogue; final design is by the project’s approved designer to the applicable standards and the project specification.
