MECH BRASS Y- STRAINER MODEL :V1-601A

Model V1-601A

Connection ends
Threaded ISO 228
Working pressure
PN16
Sizes
1/2" – 2" (DN15 – DN50)
Request a quote for this product
Or buy from the online store
Certificates & approvals

Ask us for this product's certificates.

SIZES & DIMENSIONS

Sizes & dimensions

SizeDNA (mm)B (mm)C (mm)F (mm)SW (mm)
1/2"DN153956131224.5
3/4"DN204769211233
1"DN255076211338.5
1-1/4"DN3265942715.547
1-1/2"DN4074102321953.5
2"DN5088120421967

The MECH brass y- strainer, model V1-601A, sizes 1/2″ – 2″ (DN15 – DN50), working pressure PN16. It protects meters and small valves from debris. This guide explains what it does and how it works, related models, technical data, the critical point in selection and installation, and common mistakes. For more, read the guide Y-strainers.

At a glance

  • A Y-strainer passes water through a screen in an angled leg, trapping debris, and is cleaned through the leg cap.
  • Sizes 1/2″ – 2″ (DN15 – DN50).
  • Working pressure PN16.
  • Connection: Threaded ISO 228.

Brass Y-strainer: what it does and how it works

A Y-strainer passes water through a screen in an angled leg, trapping debris, and is cleaned through the leg cap.

It is fitted ahead of water meters, reducing valves and sensitive valves on small lines.

Technical data

Specification of model V1-601A
ItemSpecification
Connection endsThreaded ISO 228
Working pressurePN16
Sizes1/2″ – 2″ (DN15 – DN50)

Dimensions for every size are in the size table at the top of the page.

Leg orientation

On horizontal lines the leg points down, with room to remove the cap.

Caution

Clean the screen after first use and then periodically.

Installation steps

  1. Check the thread type (ISO 228 parallel or NPT / ISO 7-1 taper) matches the pipe, and use the sealant or gasket suited to that thread.
  2. Hold the valve with the wrench on the end being tightened, not on the body or handle.
  3. Do not over-tighten, so the brass body is not distorted.
  4. Operate the valve after installation to check movement and sealing.

Common mistakes

  • Mixing parallel and taper threads.
  • Tightening by the valve body or handle.
  • Over-tightening the brass body.

Files and ordering

On this page: Product datasheet, MECH Brass Valves Catalogue. Add the product to your request list with size and quantity and we send a quotation, or build a submittal PDF for the consultant. Fu-Mech is the exclusive MECH agent in Saudi Arabia.

Frequently asked questions

Where should I install it?

Ahead of meters and reducing valves. See Y-strainers.

How do I clean it?

Isolate the line, remove the cap, wash the screen and refit it.

What is the working pressure of model V1-601A?

PN16 per the product data. The pressure for each size or listed model is in the size table and datasheet.

What end connection does it have?

Threaded ISO 228. Choose the connection that matches the adjacent pipe and fittings.

References

  • ISO 228 — Pipe threads where pressure-tight joints are not made on the threads
  • MECH catalogue — MECH brass valves

This guide is general information to help with selection. Figures come from the product data on this page and the MECH catalogue; final design is by the project’s approved designer to the applicable standards and the project specification.
